Battery Flying Welding–3D Galvo + Rotary Disc On-the-fly Welding

· Product Description

This rotary disc plus 3D galvo solution is mainly used for sealing side welding of 4680 and other cylindrical cells. Production
efficiency reaches 150 PPM; rotary disc revolution speed: 750 °/s, cell rotation speed: 1800 °/s, 3D galvo Z-axis height
compensation range: 16.97 mm. The unit integrates disc revolution, cell spinning, galvo Flying movement and Z-axis
compensation with microsecond-level system response and sophisticated control logic.

Technical Features
1. Cleaning efficiency: 150 PPM, welding speed: 600 mm/s
　with superior welding quality
2. Bottom surface cleaning: high-speed optocoupler with
　offline triggering ensures stable trigger during constant-speed
　Flying cleaning
3. Side surface cleaning: stable constant-speed Flying triggering
　without height compensation to match process timing
